Fuel Management Software

Inform.NET 4.0 is an annual subscription, software solution for real-time fuel and compliance management of any size network of automatic tank gauges. It allows you anytime access to critical tank gauge information – tanks, lines, inventory, deliveries, BIR, and sensors – from anywhere you have an Internet connection – computers, tablets, and smartphones. Setup email notifications and export reports to Excel or CSV file for on-demand use and sharing.

Unlimited Polling
Unlimited Polling
Unlimited Users
Unlimited Users
Remote Configuration
Remote Configuration
Easy Integration
Easy Integration

Features and Benefits

  • Web-based – flexibility in accessing critical automatic tank gauge data from anywhere there is a web browser.
  • Unlimited polling – ability to poll all sites as often as needed for real-time access to inventory and alarm data.*
  • Unlimited users – set up as many users as needed, customizing user access to your network by user role (administrator, power user or view only user) or site location.
  • Configuration change detection and restoration – see if any of the over 50 unique ATG parameters have been altered and restore any ATG on the network to its previous setting with only a click.
  • SQL and SSRS database structure – easy interfacing with other enterprise software applications.

    * Unlimited polling is dependent on user’s network capability

Expanded Capabilities

  • Configuration management – collect, review, and modify system configuration data.
  • Terminal emulator – allows for multiple commands at once.
  • TLS-450PLUS Mag Sump Sensor compatibility.
  • Pull active alarms – using the 113 commands for reporting purposes.
  • Custom commands are available – add a diagnostic command to the system such as sensor resistance.
  • TLS-350 console connect emulation system – ability to emulate the front screen of any TLS-3xx Series ATG while connecting remotely, providing a view of the screen as if physically in front of the console.


Product Form

Product Number Description


Software License Demo Version, 5 Sites, 30 Days, No Charge


Inform.NET Annual Software License Subscription Fee 1-10 Sites


Inform.NET Annual Subscription Fee 11-20 Sites, Per Site


Inform.NET Annual Subscription Fee 21-250 Sites, Per Site


Inform.NET Annual Subscription Fee 251-499 Sites, Per Site


Inform.NET Annual Subscription Fee 500-999 Sites, Per Site


Inform.NET Annual Subscription Fee 1,000-1,999 Sites, Per Site


Inform.NET Annual Subscription Fee 2,000-5,000 Sites, Per Site


Inform.NET Annual Subscription Fee 5,001-10,000 Site, Per Site


Inform.NET Annual Subscription Fee 10,000+ Sites, Per Site

Minimum Installation Requirements

In order to install Inform.NET 4.0, the user will need to be an administrator on the installation machine and be able to meet the following requirements:

  • SQL login with system administrator privileges to create and install the database objects.
  • Microsoft SQL Server Reporting Services (SSRS) login with system administrator privileges to install the reports.
  • Microsoft.NET 4.6+ installed on the target machine.
  • Microsoft SQL Server and Windows Server 2012 R2 or higher.
  • Internet or modem access to ATG network.
  • VMware and multiple server configurations supported.

Minimum Hardware Requirements

Current server polls about 29,000 locations with the same code base, but it has 8-quad core processors and 32 GB RAM.

  Physical Server Virtual Machine
CPU Cores: XEON class processors @2Ghz or greater and 1 MB L2 Cache per core 4 cores: 2 dual core processors with hyper-threading enable 4 cores assigned exclusively to SSA 2.0 in VM Ware or Hyper-V environment
Memory 4 GB minimum (16 preferred) 4 GB minimum (16 preferred)
Disk 2 X 36 GB, Raid 1 36 GB assigned, fixed size
Modem 4 or 8 multi-port modem with PCI or PCI express interface. Number of modem ports driven by number of ATGs with modems and desired response time. Recommended that ATG with modems have a dedicated phone line. Not supported


Support Consideration

  Physical Server Virtual Machine
Level of support from Titan Certified and fully supported for SSA 2.0 Certified and fully supported for SSA 2.0
Licensing License bound to Physical Server where installed License bound to Machine Name
Max Polling Throughput (IP ATGs, low latency network, inventory only poll 400 sites per minute. Max supported TCP resources setting of 400 (under admin user, Global settings) 400 sites per minute. Max supported TCP resources setting of 400 (under admin user, Global settings)

Software Service Agreement

All Inform.NET licenses will require an annual Software Service Agreement. This annual agreement is included in the site license price of the initial purchase. This agreement allows the customer access to technical support from Veeder-Root. Additionally, the customer will receive any updates, patches and releases automatically and at no extra charge.

  • This agreement is auto-renewed annually.
  • Customers have the option to cancel the Software Service Agreement after the first year.
  • If Veeder-Root does not approve the end-user’s credit application, the maintenance agreement will be terminated by Veeder-Root after the first year.
